ALETA S1

ALETA S2

Capture a truthful world.

Experience more perspective, more possibility, and more fun!
Ultracker’s Aleta S1 360 is the world’s first real in-camera
stitching camera. It brings you a whole new world of panorama image in real-time.
With the powerful Aleta S1, you can get even more than you can see!

  1 2 4
      1


Ultra high image quality

The powerful Aleta S1 is capable of taking 10 mega-pixel pictures
and 4K videos.

You can see full 360 degree image in a variety of display mode.
It offers not only wider range, but also better quality.











Advanced front-end image stitching

Aleta S1 combines image from 4 sets of sensor and lens that has higher
resolution and better brightness than normal fisheye 360 degree products.

Due to the Ultracker’s exclusive in-camera processor, you can get real-time
global image directly to a moniter through cable or to mblile device through Wi-Fi.











Excellent low light

Aleta S1’s multi-lens structure offers much higher sensitivity than other
fisheye products. It takes great night vision image with little noise.

You can enjoy the 360 degree world in both day and night.


      PIC








360 Action Camera

The compact design of Aleta S1 makes it a great 360 degree action camera.
It’s small and light that it can be simply mounted on a helmet, bike,
or a remote carrier such as drone.

Record and sharing the complete view of your activities with Aleta S1 is
just so easy.


      PIC








Applications

With real-time high quality 360 image and compact design,
Aleta S1 is capable for variety of applications such as 360 degree dashcam,
easy full-view monitoring, panorama video conference, AR application ...etc.

A whole new wolrd of 360 imge is waiting for you!




CAMERA SEPECIFICATION
Image Sensor 2.4 Megapixel CMOS Sensor X 4
Lens 2.3mm fixed lens X 4
IMAGE SETTINGS
Image Adjustment Brightness, Contrast, Saturation, Sharpness, DWDR, AEC,
AGC, AWB, Noise Reduction (2D/3D)
Image Orientation Flip, Mirror, 360˚ Rotation
VIDEO
Compression H.264
Resolution 6144 x 1792 , 1920 x 1080 , 1280 x 720
Frame Rate 6144 x 1792 6fps, 1920 x 1080 30fps, 1280 x 720 30fps
NETWORK
Wi-Fi 802.11n
POWER SUPPLY
Battery 1800mAh / 3.7V LiPo (1.5 Hour Recording)
Auxiliary power (Optional) 5V 1A (USB)
OPERATING ENVIRONMENT
Temperature 0°C ~ 40°C (32°F~104°F)
Humidity 0% - 90% (non-condensing)
APPEARANCE
Dimension 57 x 57 x 50 (WxDxH / mm)
Weight 151 g
Connectors Mico USB 2.0 X 2, Mico SD(4GB~128GB) X 1, Mico HDMI X 1
*All specifications are subject to change without notice.
